Keipro KS-Deluxe Ash-M H.H

Introduction

The Keipro KS-Deluxe Ash-M H.H is a powerful and versatile electric guitar that combines modern S-style ergonomics with the full-bodied sound of a traditional dual-humbucker instrument.

Its select swamp ash body uses a thin, open-pore satin finish and a pickguard-free design, allowing the player to see and feel the natural wood grain. This minimalist construction emphasizes direct resonance, tonal transparency and an organic playing experience.

Two YHL Marsbucker humbuckers form the tonal heart of the instrument, delivering vintage-inspired warmth, modern clarity and articulate performance under high gain. Coil splitting, a five-way selector, a roasted maple neck and staggered locking tuners further expand its versatility.

Main Features

• KS-S1 double-cutaway body contour

• Select swamp ash body

• Open-pore satin finish

• Pickguard-free design

• Roasted maple neck and fingerboard

• Slim C-shaped neck profile

• 25.5-inch scale length

• 9.5-inch fingerboard radius

• Medium nickel frets

• H.H dual-humbucker configuration

• YHL Marsbucker S2-07-N neck pickup

• YHL Marsbucker S2-07-B bridge pickup

• Alnico 5 magnets

• Five-way pickup selector

• Pull control for coil splitting

• One volume and one tone control

• Non-recessed two-point tremolo

• Staggered locking tuners

• Polymer nut

• Black ABS fingerboard inlays

• .010–.046 string gauge

Product Overview

The KS-Deluxe Ash-M H.H is described as a tonal powerhouse created to break traditional boundaries. It combines the comfort and ergonomics of a modern S-style guitar with the thick, impactful sound of a classic dual-humbucker configuration.

Unnecessary ornamentation has been removed in favor of a satin-finished swamp ash body with no pickguard. This construction gives the instrument a clean, natural appearance while emphasizing an open and direct resonant response.

The result is a flexible musical tool capable of moving between vintage-inspired warmth and the clarity required for contemporary high-gain sounds.

Body

• Body contour: KS-S1

• Body wood: Swamp ash

• Body/top colors: NT / BK

• Body finish: Satin

• Finish character: Thin, open-pore appearance

• Pickguard: None

The swamp ash body provides a resonant tonal foundation with a strong natural grain pattern. Its satin finish creates a more direct tactile connection between the player and the wood.

Neck

• Neck wood: Roasted maple

• Neck color: Natural/original

• Neck finish: Satin

• Neck profile: Slim C

• Neck thickness: 0.80–0.85 inches

• Headstock finish: Satin

• Logo color: Silver

The roasted maple neck provides stability, articulation and a responsive playing feel. Its slim C profile and satin finish are designed for comfortable rhythm and lead playing.

Fingerboard

• Fingerboard wood: Roasted maple

• Fingerboard radius: 9.5 inches

• Scale length: 25.5 inches

• Fret material: Nickel

• Fret size: Medium

• Number of frets: Not stated in the supplied specifications

• Fingerboard inlays: Black ABS

• Side dots: Black ABS

Nut and Strings

• Nut material: Polymer

• Nut width: 1.65 inches

• Nut color: Vintage white

• String gauge: .010–.046

• String manufacturer: Not specified

Dual-Humbucker Configuration

The KS-Deluxe Ash-M H.H uses two Alnico 5 YHL Marsbucker pickups. The set is designed to deliver a full and powerful sound without sacrificing articulation or dynamic response.

Neck Pickup

YHL Marsbucker S2-07-N

• Position: Neck

• Pickup type: Humbucker

• Magnet: Alnico 5

• DC resistance: 7.2K

• Character: Warm, rich and expressive

• Response: Smooth and singing

• Recommended applications: Powerful rhythm parts, melodic lead playing and warm clean sounds

The neck pickup produces a full-bodied response with a vocal, sustaining character. Its moderate output preserves clarity while providing the warmth expected from a traditional humbucker.

Bridge Pickup

YHL Marsbucker S2-07-B

• Position: Bridge

• Pickup type: Humbucker

• Magnet: Alnico 5

• DC resistance: 7.8K

• Character: Focused, articulate and transparent

• Design: Modern evolution of a vintage PAF

• Recommended applications: Driven rhythm sounds, modern rock and articulate lead tones

The bridge pickup retains classic PAF-inspired warmth while using a proprietary winding technique to tighten the low end, increase midrange density and improve high-frequency transparency.

This voicing allows individual notes to remain clear within complex chords, including when the guitar is used with substantial gain.

Electronics and Controls

• Pickup configuration: H.H

• Neck pickup: YHL Marsbucker S2-07-N, Alnico 5, 7.2K

• Bridge pickup: YHL Marsbucker S2-07-B, Alnico 5, 7.8K

• Pickup selector: Five-way

• Volume controls: One master volume

• Tone controls: One master tone

• Additional function: Pull control for coil splitting

The five-way selector and split-coil function extend the tonal range beyond conventional dual-humbucker sounds. The source does not specify the exact wiring assigned to each selector position or whether the pull control splits one or both pickups.

Bridge

• Bridge style: Two-point tremolo

• Bridge recess: None

• Saddles: Die-cast zinc

• Tremolo block: Zinc

The non-recessed two-point tremolo provides expressive pitch control while retaining a familiar playing feel.

Tuning Machines

• Type: Staggered locking tuners

• Configuration: Six in line

• Manufacturer: Not specified

The staggered posts improve the strings’ break angle across the nut, while the locking mechanism supports tuning stability and simplifies string changes.

Tonal Character

Neck Position

The Marsbucker S2-07-N provides:

• Warm and rich low frequencies

• A smooth, singing lead quality

• Full-bodied rhythm sounds

• Clear articulation

• Vintage-inspired humbucker warmth

Bridge Position

The Marsbucker S2-07-B provides:

• Tighter bass response

• Increased midrange density

• Transparent high frequencies

• Strong note separation

• Clear complex chords under high gain

• Modern punch with vintage PAF character

Split-Coil Sounds

The pull control adds brighter and leaner split-coil sounds to the guitar’s dual-humbucker foundation. This gives the player additional options for clean passages, defined rhythm work and more cutting tones.

Complete Specification Summary

General

• Model: Keipro KS-Deluxe Ash-M H.H

• Body contour: KS-S1

• Pickup configuration: H.H

• Scale length: 25.5 inches

• Fingerboard radius: 9.5 inches

• Pickguard: None

Body

• Wood: Swamp ash

• Colors: NT / BK

• Finish: Satin

• Finish style: Open-pore appearance

Neck and Fingerboard

• Neck wood: Roasted maple

• Neck finish: Satin

• Profile: Slim C

• Thickness: 0.80–0.85 inches

• Fingerboard: Roasted maple

• Radius: 9.5 inches

• Frets: Medium nickel

• Inlays: Black ABS

• Side dots: Black ABS

• Headstock finish: Satin

• Logo: Silver

Nut and Strings

• Nut material: Polymer

• Nut width: 1.65 inches

• Nut color: Vintage white

• String gauge: .010–.046

Electronics

• Neck pickup: YHL Marsbucker S2-07-N, Alnico 5, 7.2K

• Bridge pickup: YHL Marsbucker S2-07-B, Alnico 5, 7.8K

• Selector: Five-way

• Controls: One volume and one tone

• Additional function: Pull control for coil splitting

Hardware

• Bridge: Non-recessed two-point tremolo

• Saddles: Die-cast zinc

• Tremolo block: Zinc

• Tuners: Staggered locking tuners

Final Overview

The Keipro KS-Deluxe Ash-M H.H is built for players who appreciate the raw beauty and resonance of natural wood but require the power and flexibility of a modern tonal system.

Its swamp ash body and roasted maple construction create a clear, responsive foundation, while the Marsbucker humbuckers deliver a balance of vintage warmth, modern definition and high-gain articulation.

Rather than functioning as a simple collection of components, the KS-Deluxe Ash-M H.H is designed as a complete system for musical expression—balancing organic character with focused, powerful performance.
