OVERVIEW The Jan Ray was designed to recreate the punchy clear tone of the Blackface Fender amps from the 60’s. So-called the “Fender Magic 6” sound. An easy to handle overdrive keeping the characteristics of the guitar, with great sustain without any unnatural compression.
FOOTSWITCH toggles effect on/bypass (blue LED indicates on) VOLUME knob adjusts overall volume of effect BASS knob cuts low end frequencies GAIN knob adjusts overdrive intensity TREBLE knob cuts high end frequencies from post-overdrive signal
OPERATION: Install a 9V battery in the unit (see below) or plug in a suitable 9Vdc, center negative power supply. Plug your guitar into the input jack and connect your amp to the output jack. True bypass Input Impedance:400k ohm Output Impedance:1k ohm Power Connector:9Vdc, center negative, 2.1mm x 5.5mm (NOT INCLUDED) Dimensions:11.5*6.5*5.5CM
